Soleus Air NDY-15 - Manual (Page 4)

SPECIFICATIONS
Voltage Rating 115 V (60Hz)
Power Consumption 600/900/1500W
Unit Size 5.8 in. (W) x 15.2 in. (D) x 27.5 in. (H)
Unit Weight 26 lbs
PRODUCT DIAGRAM
ASSEMBLY
1. Remove the heater body, two wheelbases, and two U-shaped connecting screws with
wing nuts from the box. Remove the packaging materials and keep for future storage.
2. Be certain the heater is unplugged and the controls are set to off. Set the heater on the
floor upside down. The heater may make some noise as the liquid settles.
3. Remove the wing nuts from the U-shaped connecting screws. Place one of the U-shaped
connecting screws between the front two fins of the heater and over the joint so that the
threads on the screw project upward.
