P A R T N A M E S
1 Safety door latches
The oven will not operate unless the door is securely closed.
2 Door hinges
3 Door seals and sealing surfaces
4 Door handle
Pull to open door.
5 Turntable motor shaft
6 Removable turntable support
7 Removable turntable
Place the turntable on the turntable support securely. The turntable will rotate clockwise or
counterclockwise. Only remove for cleaning.
8 Ventilation openings (Rear)
9 Oven light
It will light when oven is operating.
10 Waveguide cover: DO NOT REMOVE.
11 Control panel display
12 Start/Minute Plus pad
13 Stop/Clear pad
MICROWAVE OVEN PARTS
DOOR CLOSED DOOR OPEN
