Power Rating: (@ 8
Ω):
500 Watts Program
Frequency Response:
60 Hz – 15 kHz ± 3 dB
Operating Impedance:
8 Ohms
Sensitivity:
97 dB SPL @ 1W/1m
Crossover Frequency:
2.3 kHz (24 dB Per Octave)
LF Driver:
15
″ heavy-duty driver
2.5
″ voice coil (Kapton Former)
50 oz. barium ferrite magnet
HF Driver:
1.75" titanium compression driver
Mounting:
Integral 1 3/8
″ Pole Mount Receptacle
15º wedge monitor position, 30º wedge monitor position, Ten Fly Points
Weight:
50 lbs.
22.7kg
Dimensions:
30
″ (h) x 19″ (w) x 17″ (d)
(762mm) (h) x (483mm) (w) x (432mm) (d)
11
dB500 Specifications
500
a
dB
500
a
dB
19
″
(483mm)
19
″
(483mm)
30
″
(762mm)
17
″
(432mm)
