EXTERNAL SCHEMATIC AND INSTALLATION
FRONT PANEL
Note: The graphics are for representation only.
1
2
3
5
7
10
9
8
4
6
10
3.Program Up Button
2.Menu Button
1.AV/TV Button
4.Program Down Button
5.Volume Up Button
6.Volume Down Button
7.Standby Button
8.Power Indicator
9.Remote Sensor
10.Speakers
