9 10
Power Supply Switching ICs
Type No. Package
Input voltage (V)
Applications P
VCC1 VCC2 VCC3
LV5621LP VCT16(2.6×2.6) 2.7 to 4.8 3 3.5 to 5.2 For DSCs and game machines 20
LV5622LP VCT16(2.6×2.6) 2.7 to 4.8 3 3.5 to 5.2 For DSCs and game machines
LV5625V SSOP16(225mil) 1.45 to 3.4 3 3.5 to 5.2 For DSCs and game machines
Power ICs with a Watchdog Timer Function
Type No.
Absolute
maximum ratings
Input voltage
(V)
Total power
dissipation
(W)
Package
Function reset
logic output
Reset
hold
5V
regulator
control
Regulator
output
ON/OFF
Edge
detection
Watchdog
time typ
(Ct=2μF)
P
LA5690D 41 0.5 DIP8(300mil) Noninverted/Inverted ● ● 5ms
LA5690S 41 0.5 SIP9 Noninverted/Inverted ● ● 5ms
LA5691S 41 0.5 SIP9 Inverted ● ● ● 5ms
LA5692D 41 0.5 DIP8(300mil) Inverted ● ● ● 40ms
LA5692M 41 0.37 MFP8(225mil) Inverted ● ● ● 40ms
LA5692S 41 0.5 SIP9 Inverted ● ● ● 40ms
LA5693AM 41 0.37 MFP8(225mil) Inverted ● ● 40ms 21
LA5693D 41 0.5 DIP8(300mil) Inverted ● ● 40ms 21
LA5693M 41 0.5 MFP8(225mil) Inverted ● ● 40ms 21
Series Power Supply ICs Continued from preceding page.
Type No. Type
Output
Current
(A)
Output voltage (V)
Absolute
maximum ratings
Package Features P
1.8 2 2.5 3 3.3 3.4 3.5 4 5 6 7 8 9 10 12 15 18 20 24
Input
voltage
(V)
Total power
dissipation
(W)
L780S12
Positive
voltage
1.0 ● 35 1.75 220-5H
1A general-purpose voltage
regulator, 12V output voltage,
1A output current, strobe
pin, thermal protection and
overcurrent limiter circuits
L780S15
Positive
voltage
1.0 ● 35 1.75 220-5H
1A general-purpose voltage
regulator, 15V output voltage,
1A output current, strobe
pin, thermal protection and
overcurrent limiter circuits
L780S18
Positive
voltage
1.0 ● 35 1.75 220-5H
1A general-purpose voltage
regulator, 18V output voltage,
1A output current, strobe
pin, thermal protection and
overcurrent limiter circuits
L78MR05
Positive
voltage
0.5 ● 35 1.75 220-5H
5V voltage regulator with
reset pin, 5V output voltage,
0.5A output current
L78MR06
Positive
voltage
0.5 ● 35 1.75 220-5H
6V voltage regulator with
reset pin, 6V output voltage,
0.5A output current
L78MR08
Positive
voltage
0.5 ● 35 1.75 220-5H
8V voltage regulator with
reset pin, 8V output voltage,
0.5A output current
L78MR12
Positive
voltage
0.5 ● 35 1.75 220-5H
12V voltage regulator with
reset pin, 12V output voltage,
0.5A output current
L78MS05J
Positive
voltage
0.5 ● 35 1.75 220-5H
5V voltage regulator with strobe
pin, 5V output voltage, 0.5A output
current, strobe pin (Features a low
quiescent current of 35μA)
L78MS05JSMP
Positive
voltage
0.5 ● 35 2.0 SMP5
5V voltage regulator with strobe
pin, 5V output voltage, 0.5A output
current, strobe pin (Features a low
quiescent current of 35μA)
L79M05T
Negative
voltage
0.5 ● -35 1.0 TP3H
-5V 3 pin voltage
regulator (minus output),
−5V/0.5A, Pd: 1.0W
L79M06T
Negative
voltage
0.5 ● -35 1.0 TP3H
-6V 3 pin voltage
regulator (minus output),
−6V/0.5A, Pd: 1.0W
L79M08T
Negative
voltage
0.5 ● -35 1.0 TP3H
-8V 3 pin voltage
regulator (minus output),
−8V/0.5A, Pd: 1.0W
L79M09T
Negative
voltage
0.5 ● -35 1.0 TP3H
-9V 3 pin voltage
regulator (minus output),
−9V/0.5A, Pd: 1.0W
L79M10T
Negative
voltage
0.5 ● -35 1.0 TP3H
-10V 3 pin voltage
regulator (minus output),
−10V/0.5A, Pd: 1.0W
L79M12T
Negative
voltage
0.5 ● -35 1.0 TP3H
-12V 3 pin voltage
regulator (minus output),
−12V/0.5A, Pd: 1.0W
Dual-Protection ICs (for Rechargeable Lithium-ion Batteries) ●: New products and
❈: Development
Type No.
Absolute maximum ratings
Package Functions/Features P Input voltage
(V)
Total power
dissipation
(W)
● LV5113T -0.3 to +12 0.17 MSOP8(150mil) 2-cell Lithium-ion rechargeable battery protection IC
● LV5122T -0.3 to +12 0.17 MSOP8(150mil) 2-cell Lithium-ion rechargeable battery protection IC
❈ LV51130T -0.3 to +12 0.17 MSOP8(150mil) 2-cell Lithium-ion rechargeable battery protection IC
● LV51131T -0.3 to +12 0.17 MSOP8(150mil) 2-cell Lithium-ion rechargeable battery protection IC
❈ LV51132T -0.3 to +12 0.17 MSOP8(150mil) 2-cell Lithium-ion rechargeable battery protection IC
❈ LV51133T -0.3 to +12 0.17 MSOP8(150mil) 2-cell Lithium-ion rechargeable battery protection IC
● LV51134T -0.3 to +12 0.17 MSOP8(150mil) 2-cell Lithium-ion rechargeable battery protection IC
❈ LV51135T -0.3 to +12 0.17 MSOP8(150mil) 2-cell Lithium-ion rechargeable battery protection IC
❈ LV51136T -0.3 to +12 0.17 MSOP8(150mil) 2-cell Lithium-ion rechargeable battery protection IC
● LV51137T -0.3 to +12 0.17 MSOP8(150mil) 2-cell Lithium-ion rechargeable battery protection IC
● LV51138T -0.3 to +12 0.17 MSOP8(150mil) 2-cell Lithium-ion rechargeable battery protection IC
❈ LV5125T -0.3 to +12 0.17 MSOP8(150mil) 2-cell Lithium-ion rechargeable battery protection IC
❈ LV51110T -0.3 to +7 0.35 SOT-23-6 1-cell Lithium-ion rechargeable battery protection IC
❈ LV51110LF -0.3 to +7 0.3 SON5(1.6×2.0) 1-cell Lithium-ion rechargeable battery protection IC
❈ LV51111T -0.3 to +7 0.35 SOT-23-6 1-cell Lithium-ion rechargeable battery protection IC
❈ LV51111LF -0.3 to +7 0.3 SON5(1.6×2.0) 1-cell Lithium-ion rechargeable battery protection IC
❈ LV51112T -0.3 to +7 0.35 SOT-23-6 1-cell Lithium-ion rechargeable battery protection IC
❈ LV51112LF -0.3 to +7 0.3 SON5(1.6×2.0) 1-cell Lithium-ion rechargeable battery protection IC
❈ LV51113T -0.3 to +7 0.35 SOT-23-6 1-cell Lithium-ion rechargeable battery protection IC
❈ LV51113LF -0.3 to +7 0.3 SON5(1.6×2.0) 1-cell Lithium-ion rechargeable battery protection IC
❈ LV51114T -0.3 to +7 0.35 SON5(1.6×2.0) 1-cell Lithium-ion rechargeable battery protection IC
Continued on next page.
Dual-Protection ICs
Type No.
Absolute maximum ratings
Package Functions/Features P Input voltage
(V)
Total power
dissipation
(W)
LA5695M 18 0.4 MFP14(225mil)
Protection ICs for heating/cooling equipment and OA equipment, Built-
in abnormal supply voltage detection circuit, driver output with built-in
output delay circuit, can be controlled from 8 input pins.
