Page 44

Chapter 4
Recording and Playback
4-2
Chapter 4
Recording and Playback
4-1
Recording
Z
EE
TC
VID. IN PB/EE CONFI
SDI
DISABL
TCGSET
CTL/TC MENU
59.94
POWER switch: ‘I’ side (on)
Audio selection function selector buttons
(see page 2-5): Select the input audio signal.
REMOTE buttons
(see page 2-3): off
REC controls
(see page 2-7):
Adjust the audio recording levels.
PB/EE setting
(see page 9-3): PB
CTL/TC setting
(see page 9-3):
Select the time data to be
displayed.
VID.IN setting
(see page 9-3):
Select the input video signal.
RECINH setting
(see page 9-7):
OFF
CONFI setting
(see page 9-3):
ENABLE
PREREAD setting
(see page 9-7): OFF
CONFI (ON)/PREREAD indicators
(see page 2-9): lit
Audio monitor signal selection buttons
(see page 2-6):
Select the audio channel to be monitored.
