Ohm. You will hear the master signal in your headphones if
you haven’t selected any of these options: PFL (31),
EFFECT (57) and FILTER (56).
56
FILTER
When the FILTER switch (56) is selected, you will hear the
mixed master signal before the activated DJ filter or
master effect. When the FILTER switch is in its up position
(off), the master signal is set to post-filter.
57
EFFECT
By pressing the EFFECT switch you can pre-listen to the
internal effect signal.
NOTE : The PFL and EFFECT monitor switches must be off
monitor the filter from the headphone output.
6
Mic Inputs
(Mic1 + Mic2)
Sensitivity
-46dBu
Impedance
10kOhm
S/N Ratio
>80dB
THD+Noise
<0,1%
EQ High
+/-15dB, 10kHz
EQ Mic
+/-15dB, 1,1kHz
EQ Low
+/-15dB, 50Hz
Input 1-4
Sensitivity
-20dBu (Line1+2)
-60dBu (Phono/RIAA-Filter)
Impedance
100kOhm (Line1+2)
50kOhm (Phono)
S/N Ratio
>85dB
THD+Noise
<0,1%
EQ High
+/-15dB
EQ Low
+/-15dB
Parametric EQ
+/-25dB (100Hz-10kHz)
AUX-Level
0dBu
Master
Effect-Loop
0dBu
Booth
0dBu
Master1
0/+6dBu switchable
Master2
+6dBu
Internal Effects
Frequency Range
20Hz-15kHz
THD+Noise
0,025%
S/N Ratio
86db
Effects
8 x Reverberation
4 x Delay
4 x Flanging
Filter
Mode
Band/Notch
Frequency Range
50Hz-15kHz, 24dB/Octave
Resonance
+6dB
Headphones
Impedance
30-200Ohms
Frequency Range
20Hz-20kHz
Mains
Power Consumption
50VA
Voltage Selector/Fuse
230V/500mA
115V/1A
100V/1A
Dimensions
Front
483mmx355mm (19"x8)
Chassis
436mmx352mmx100mm
Weight
approximately 10kg
This unit has been designed and manufactured using qual-
ity components. Therefore, it is warranted to be free from
defects in materials (limited as specified below), and work-
manship for a period of twelve (12) months from the origi-
nal purchase date. During this period, all service and parts
necessary to repair a defect will be free of charge. This lim-
ited warranty applies to mechanical parts which are subject
to wear and tear as specified:
• Faders, specified durability: 15,000 cycles
• Rotary potentiometers, specified durability: 10,000 cycles
• Switches, specified durability: 10,000 cycles
Consequently, the parts listed above are warranted to be
free from defects in materials and workmanship for a peri-
od of thirty days (30) days from the original purchase date.
FOR THE WARRANTY TO BE VALID, PLEASE COMPLETE THE
ONLINE WARRANTY REGISTRATION FORM FOUND AT
W W W. S TA N T O N M A G N E T I C S . C O M
Stanton Magnetics, LLC, 2821 Evans Street • Hollywood, FL 33020 (954) 929-8999 Fax: (954) 929-0333
© 2000, Stanton Magnetics, LLC
TECHNICAL CHARACTERISTICS
WARRANTY
