TROUBLESHOOTING AND MAINTENANCE
85
8
3 Gently pull the TD cartridge
out while pressing the lock
release button.
4 Remove the TD cartridge from the bag. Remove the protective
paper. Hold the cartridge on both sides and shake it
horizontally four or five times. Hold the tab of the protective
cover and pull the tab to your side to remove the cover.
5 While pushing the lock release button,
gently insert the TD cartridge until it
locks into place.
• After removing the TD cartridge, do not shake it or tap on it. Doing so
may cause toner to leak from the cartridge. Put the old cartridge
immediately in the bag contained in the box of the new cartridge.
• Dispose of the old TD cartridge in accordance with local regulations.
Lock release button
Note
4 or 5 times
Lock release button
