14 Hardware Installation Guide
Print Server Controls and Technical Data
Characteristics Values
Printer Connector - 1 x Centronics
- 1 x USB 2.0 highspeed (expandable to 4 ports)
Network Connection
logical:
physical:
- IEEE 802.11g
- WLAN Module
Operating Environment - Ambient temperature: 5 - 40 °C
- Relative humidity: 20 - 80 %
Dimensions - Length 117 mm
- Width 70 mm
- Height 151 mm
- Weight 370 g
1) Status button
2) USB port
3) Centronics
connector
4) Connector for SEH
power pack
1) Power On/Off LED (green)
2) Network activity LED (yellow):
The LED lights up when data
packets are being received.
3) Link indicator LED (green):
The LED lights up when a
wireless connection to the
network is available.
