9
Starting the Engine (continued)
WARNING!
Never start the engine from the
operating position.
WARNING!
The cutting attachment may
rotate when the engine is started!
When the Engine Starts...
After the engine starts, allow the engine
to warm up at idle or 3 minutes before
operating the unit.
Advancing the throttle makes the
cutting attachment turn faster; releasing
the throttle permits the attachment to
stop turning. If the cutting attachment
continues to rotate when the engine
returns to idle, carburetor idle speed
should be adjusted (see “Adjusting
Engine Idle” below).
■
■ IMPORTANT!
If the engine fails to start after several attempts
with the choke in the closed position, the
engine may be flooded with fuel. If flooding is
suspected, move the choke lever to the open
position and repeatedly pull the recoil starter
to remove excess fuel and start the engine.
If the engine still fails to start, refer to the
troubleshooting section of this manual.
When the engine starts, slowly move the
choke lever to the “OPEN” position. See
Figure 15. (If the engine stops after the
initial start, close the choke and restart.)
5.
Idle the engine briefly before stopping
(about minutes), then slide the ignition
switch to the “O” (Engine OFF) position.
Stopping the Engine
Adjusting Engine Idle
Figure 16
Figure 17
The engine must return to idle speed
whenever the throttle lever is released.
Idle speed is adjustable, and must be set
low enough to permit the engine clutch to
disengage the cutting attachment.
Idle Speed Adjustment
WARNING!
The cutting attachment
must NEVER rotate at engine
idle! If the idle speed cannot be
adjusted by the procedure described
here, return the trimmer to your
Shindaiwa dealer for inspection.
Place the trimmer on the ground, then
start the engine, and then allow it to idle
-3 minutes until warm.
If the attachment rotates when the
engine is at idle, reduce the idle speed
by turning the idle adjustment screw
counter-clockwise. See Figure 17.
If a tachometer is available, the engine idle
speed should be final adjusted to 3,000
(±50) rpm (min -1 ).
Carburetor fuel mixture adjustments are
preset at factory and cannot be serviced
in the field.
1.
.
3.
4.
Idle Adjusting
Screw
Figure 15
Open
