SM06 Rev. 4.10 Tac/Com Control Head Manual
1.6.5
Interface-Specific Suffix Information
The position of the digit in the code reflects the position of the card in the control. The
code position from left to right equals the relevant card position from top to bottom.
TH450 - 2NNNE
A = ARINC 2 of 5 Comm M = Midland Syn-Tech I
B = Blank (No Controls) N = NAT NT-Series
C = Flitefone 40 O = Not Assigned
D = Motorola Astro/XTL Series P = RT9600/7200 Single Connector
D1 = Motorola Astro/XTL with zone function Q = RT9600 with Tones, No Guard
E = NT Slot. Controls only. No Card
R = RT9600/7200 Plug Compatible
F = Flexcomm S = Motorola URC-200
G = Flex Slot. Controls only. No Card T = NAT NT-Series with Transcrypt
H = NTX Series with USFS Guard U = RT9600 with USFS Guard & Internal
I = Not Assigned 32 Tones
J = NAT Tac/Com NTX Series V = NAT NT-Series with USFS Guard
J1 = Chelton 805-1, 905-2, 915-1 W = Not Assigned
K = Midland Syn-Tech XTR X = Not Assigned
L = Motorola Spectra Y = Serial I/O Expansion Port
L1 = Motorola Spectra with zone function Z = General Slave Interface
Above example: 3 NAT & 1 Empty (Empty in bottom slot)
Earlier Tac/Com I controls had a different numbering scheme, using only a three
character suffix. If you need to convert an older number to a new one, contact NAT
for details, or consult revision 1.xx of this manual.
End of section 1
