Sound Performance Lab 9842 - Manual (Page 6)

Transient Designer
6
Before connecting the T RANSIENT D ESIGNER switch power off at all
connected units.
The T RANSIENT D ESIGNER is fitted with XLR-connectors for balanced
operation. The following illustration shows the pin-wiring:
To ensure optimal signal quality, SPL has developed a new hybrid-
component balanced input/output stage using all laser-trimmed
resistors with a tolerance of 0.01%. This approach has resulted in
an exceptionally high CCMR (common mode rejection); -80 dB at
1kHz and -75 dB at 10 kHz.
Should the need arise to use the XLR connectors in an unba-
lanced system, pin 3 of the XLRs should be grounded. The follo-
wing illustration shows how to properly unbalance a balanced
signal:
Rear panel T
R
ANSIENT
D
ESIGNER
,model 9842
Connections
2 1
3
1 2
3
Pin wiring: XLR output
1 = GND, 2 = hot (+), 3 = cold (-)
Pin wiring: XLR input
1 = GND, 2 = hot (+), 3 = cold (-)
soundperformancelab
.com
TO REDUCE RISK OF F
IRE
OR EL
ECTRIC SHOCK DO
N
O T E
XPOSE
THIS UNIT
TO RAIN OR MOIS
TURE.
DISC
ONNECT
MAIN
S
BEF
ORE REMO
VING C
O VER.
VOLTAGE/
FUSE
XLR W iring: 1 = GND/ 2 = (+)/ 3 = (–)
Output
4
Input
4
Output
3
Input
3
Output
2
Input
2
Output
1
Input
1
GND LIFT
AVIS: RISQUE DE CHOC ÉL
ECTRIQUE - NE P
A S OUVRIR
RISK OF EL
ECTRIC SHOCK
DO N
O T OPEN
C
A
UTION
Serial #
WARNING
Sound P
erformance Lab
SP
L electr
onics
GmbH
41
372 Niederkrüchten
Germany
Made in Germany
230
V
50 Hz Fuse: 200
m
A
115
V
60 Hz Fuse: 400
m
A
230 V
Input
4
Output
4
Input
3
Output
3
Input
2
Output
2
Input
1
Output
1
