Stanley Stud Sensor 150

The Stud Sensor 150 uses electronic

signals to locate the edges of studs, joists

or live AC wires through drywall or other

common building materials. Depth detection

selected by activation button for ½ inch,

1 inch and 1½ inch. Once the edge of a stud has

been detected, the Stud Sensor 150 displays red

LED’s and sounds an audible tone. A marking

channel allows you to easily note the stud

edges on the wall.

Note: Read all instructions prior to operating

the Stud Sensor 150 and DO NOT remove any

labels from the tool.

OPERATING INSTRUCTIONS

Battery

1

Open door on back of unit and connect a

9 volt battery (not included) to clip. Put battery

back into case and close back battery door.

Note: Recommend to replace a new 9 volt

battery when low battery - flashing green

LED.

Usage

Selecting Scanner Depth Mode

3

• Depress and hold activation button once

(1x) to select to ½” read depth detection.

The ½” mode LED will illuminate.

• Depress and hold activation button twice

(2x - double-click) to select to 1” read depth

detection. The 1” mode LED will illuminate.

• Depress and hold activation button three

times (3x - triple-click) to select 1½” read

depth detection. The 1½” mode LED will

illuminate.

Note: For best results the depth mode

selected should be based on the thickness of

the surface material being scanned.

Detecting Wood / Metal Studs

2

Hold the Stud Sensor 150 flat against

the surface, making firm contact.

3

Press in and hold the activation button.

The green and top red LED will light.

4

When the red LED goes off, the unit is

calibrated.

5

Keep holding the activation

button during all of the following procedures.

Note:

3

The unit cannot be moved before

calibration is complete.

2

While calibrating,

the Stud Sensor 150 must not be placed

directly over a stud, dense material such as

metal, or over a wet or newly painted area,
or it will not properly calibrate.

11

If the red

LED stays lit, move the Stud Sensor 150 to

a different location and try again. Releasing

the activation button will turn off the sensor.

6

Slide the Stud Sensor 150 slowly across

the surface in a straight line.

9

As it detects

a stud, the red LED’s will go on.

6

When it

detects the stud edge, the top LED will go

on and an audible tone will sound. Use the

marking channel located at the top of the
unit to mark the stud edge.

7

Repeat the

above steps from the other side of the stud.

Coming from the opposite direction, mark
the other edge of the stud.

8

The midpoint

of the two marks indicates the stud center.

Detecting Live AC Wires

10

The live wire red LED will illuminate and

the Stud Sensor 150 sounds an audible tone,

warning when in the proximity (typically

within 4” to 18” along the surface) from a

live wire.

Note: Static electrical charges that can

develop on drywall and other surfaces will

spread the voltage detection area many

inches on each side of the actual electrical

wire. To aid in locating the wire position,

scan holding the unit ½” away from the

wall surface or place your other hand on the

surface approximately 12” from sensor.

Warning: Shielded wires or wires in metal

conduits, casings, metallized walls or thick,

dense walls will not be detected. Always

turn off AC power when working near wiring.

Cautions on Operating

You should always use caution when nailing,

cutting and drilling in walls, ceilings and

floor that may contain wiring and pipes near

the surface. Always remember that studs

or joists are normally spaced 16 inches or

24 inches apart and are 1½ inches in width. To

avoid surprises, be aware that anything closer

together or of a different width may not be a

stud.

OPERATING TIPS

The Stud Sensor 150 is designed for use only on

interior surfaces.

Prevent Interference

To ensure best performance from the Stud

Sensor 150, keep your free hand at least 6

inches away from the unit and wall surface

while testing or scanning surfaces.

Conventional Construction

Doors and windows are commonly constructed

with additional studs and headers for added

stability. The Stud Sensor 150 detects the

edge of these double studs and solid headers

as a single, wide stud.

Surface Differences

The Stud Sensor 150 will scan through

common building materials, Including:

• Gypsum drywall

• Plywood sheathing

• Hardwood floors

• Linoleum over wood

• Wallpaper

The scanner cannot scan through:

• Carpeting

• Foil faced materials

• Ceramic tile

• Cement or concrete

• Metal & plaster walls

Wallpaper

There will be no difference in the function

of the Stud Sensor 150 on surfaces covered

with wallpaper or fabric unless the coverings

used contain metallic foil or fibers.

Ceilings

When dealing with a rough surface such as

a sprayed ceiling, utilize a piece of cardboard

when scanning the surface. Run through

the calibration technique described earlier

with the piece of cardboard too, to assure

best performance of the unit. Also, it is

particularly important in this application to

remember to keep your free hand away from

the unit.

Note: The thickness, density and moisture

content of the surface material will affect

the sensing depth.

IMPORTANT SAFETY NOTICE

Insure proper detection of live wires. Always

hold the Stud Sensor 150 in the handle area

only. Grasp between fingers and thumb while

making contact with your palm.

SPECIFICATIONS

(At 35-55% relative humidity)

Battery

9 volt (not included)

Depth Range

Wood or Metal Studs Up to 1½” (38 mm) through drywall
Live AC Wires (120 volts AC) Up to 2” (50 mm) through drywall

Accuracy - Stud Center (Scanning and marking the stud from two sides stud center)

Wood

±1/8” (3 mm)

Metal

±1/4” (6 mm)

Operating Temperature +32°F to +120°F (-0°C to +49°C)
Surface Temperature

-4°F to +150°F (-20°C to +66°C)

WARRANTY

Stanley Tools warrants the Stud Sensor 150

against defects in material and workmanship

for one year from the date of purchase. Stanley’s

liability under this warranty is limited the

replacement of the unit. Any attempt to repair

the product by other than factory authorized

personnel will void this warranty. Calibration,

batteries and maintenance are the responsibility

of the user. Where permitted by law, Stanley is

not responsible for incidental or consequential

damages. Agents of Stanley cannot change

this warranty. Stanley is not responsible for

damage resulting from wear, abuse or alteration

of this product. The user is expected to follow

ALL operating instructions. This warranty may

provide you with additional rights that vary by

state, province or nation.

WARNING:

Protect Your Eyes, Wear Safety Goggles.

©2012 STANLEY TOOLS

www.STANLEYTOOLS.com

701 East Joppa Road

Towson, Maryland 21286
