3
Sears 003 - Sch 549 11/2/95
Parts
This section shows an illustration of your battery charger. Use it to become familiar with where all the parts are
located, and what they look like.
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Replacement Parts List Sears 47003
Description Part Number
Cover 3799001402
Heatsink/Diode Assembly 2299000846
Base 3799001382
AC Power Cord 90026055
Transformer 93026312
Output Cable 3899000515
Circuit Breaker (20A) 3999000072
50A Clamp (1) 2299000248
Sleeving Red (2) required 0399000007
Sleeving Black (2) required 0399000008
Meter 5399100092
Switch SPDT 0499000031
Front Panel 3799001392
Decal 0899000532
Handle 3599000240
Screw 8-18 x 3/8" (4) 5181806256
Owner's Manual and Parts List (Not Shown) 0000000549
Wiring diagram
