Sterling STT 1600 - Manual (Page 52)

”Re gen er a tion” Blo wer
Re move the pro tec tive grid of the blower (pos. 3).
Loosen the nut (pos. 1).
Loosen and re move the screw (pos. 2).
Slide mo tor with car rier flange plate (pos. 6) to wards the car rier flange hous ing (pos. 4).
Re place ment: Re move de fec tive V-belts (pos. 5), put on new ones.
Re-tensioning: Ad just belt ten sion by means of screw (pos. 2) in ac cor dance with the in for ma tion
plate.
Tighten the nuts on threaded bolt (pos. 1) again.
Mount the pro tec tive grid of the blower (pos. 2).
Mount the side pan els.
F At ten tion should be given to ex act align ment of the V-belt pul leys.
