CONTROL PANEL AND LED DISPLAY
CONTROL PANEL
TIMER Button Press this button to turn the timer on/off.
MODE Button
Press this button to select among the modes of cooling, dehumidifying, fanning, or
heating.
TEMP – Button This button decreases the room temperature/timer hours.
TEMP + Button This button increases the room temperature/timer hours.
ON/OFF Button Press this button to turn the unit on or off.
FAN SPEED
Button
During the modes of cooling, heating and fanning, press this button to choose high,
medium or low fan speed. In dehumidifying mode, this button is inoperable.
SWING Button Press this button to oscillate the vertical louvers or to stop oscillation.
LED DISPLAY
A. Cool Mode
B. Dehumidify Mode
C. Fan Mode
D. Heat Mode
E. Signal receiver
F. Timer On/Off
G. Fan Speed (Low, High, Medium)
H. Indicates Time and Temperature
I. Indicates when Compressor is
working
8
