SV Sound PB10-NSD - Manual (Page 11)

SV Sound
Chapter 7-2
Specifications
Model Name: PB10-NSD
Configuration: Powered Box, front-firing 10” woofer
Design: Vented
Dimensions: 19” High x 15” Wide x 21” Deep
H x W x D 48 cm H. x 38 cm W. x 53 cm D.
Weight: 60 lbs (27 kg)
Voltage (fixed):
110~120V/60hz (US/Canada/South America)
220~240V/50hz (Europe, Russia, other)
Driver:
10” SVS designed/built “NSD” woofer with high
- excursion synthetic surround, polypropylene
cone with cast basket, high-temp US voice coil
and integral cooling vents
Frequency Response:
(quasi-anechoic) 20Hz - 150Hz ± 3dB (typical in-room response
3-5Hz deeper) .
Inputs/Outputs: RCA
Controls:
Gain, continuously variable phase, auto on,
replaceable fuse.
Power Handling: 325 watt RMS
Crossover: Not applicable (N/A)
Enclosure Material:
.75” - 1” Medium Density Fiber-board (MDF)
with internal CNC’d bracing, and charcoal
black finish
