TABLE 3: POINTS LIST IN OBJECT ORDER (CONTINUED)

Read/

Write

BACnet

Object

Type

BACnet

Object

Inst

Descriptor

Default

Min

Max

Point Description

R

(5) BV

19

LOW_AMB_OVRD

–

–

–

Low Ambient Temperature (0=comps not
overridden by LAT, 1=comps overridden)

R

(5) BV

20

POP_ENABLED

–

–

–

Pre-Occupancy Purge Enabled

R

(5) BV

21

FAN_ON_W_SEN

–

–

–

CV - Indoor Fan Operates with Space
Sensor Present Option Enabled

R

(5) BV

22

SAT_COOLING

–

–

–

Supply Air Temperature Limit for Cooling
Enabled

R

(5) BV

23

COOLING_ENA

–

–

–

Cooling Mode Enabled

R

(5) BV

24

SAT_HEATING

–

–

–

Supply Air Temperature Limit for Heating
Enabled

R

(5) BV

25

HEATING_ENA

–

–

–

Heating Mode Enabled

R

(5) BV

26

SEN_FAULT_EN

–

–

–

Space Sensor Fault Override (Construction
Mode) Enabled

R

(5) BV

28

INTELLI-STRT

–

–

–

Intelli-Start Enabled

R

(5) BV

29

BP_SENS_INST

–

–

–

Building Static Pressure Sensor Installed

R

(5) BV

30

EX_FAN_STAT

–

–

–

Exhaust Fan Output Status (0=output is OFF,
1=output is ON)

R

(5) BV

31

ECONO_STATUS

–

–

–

Economizer Output Status (0=not Free
Cooling, 1= Free Cooling)

R

(5) BV

32

FRECOOL_STAT

–

–

–

Free Cooling Mode Status (0=comps not
overridden by Econo, 1=comps overridden)

R

(5) BV

33

COM_VENT_STA

–

–

–

Comfort Ventilation Mode Status (1=control
is in Comfort Vent mode, 0= it is not)

R

(5) BV

34

CVM_COOLING

–

–

–

Comfort Ventilation Mode for Cooling
Enabled

R

(5) BV

35

CVM_HEATING

–

–

–

Comfort Ventilation Mode for Heating
Enabled

R

(5) BV

36

ECO_L_TO_SAT

–

–

–

Economizer Loading to Control Supply Air
Temperature Enabled

R

(5) BV

37

OAH_SENSOR

–

–

–

Outside Air Humidity Sensor Enabled

R

(5) BV

38

RAH_SENSOR

–

–

–

Return/Inside Air Humidity Sensor Enabled

R

(5) BV

39

DEMAND_VENT

–

–

–

Demand Ventilation (using Inside Sensor)
Enabled

R

(5) BV

40

E_IFAN_STAT

–

–

–

Elite Indoor Fan Output Status (0=output is
OFF, 1=output is ON)

R

(5) BV

41

E_FAN_ OVER

–

–

–

Elite Fan Overload Switch Input Status
(1=closed, 0=open/fault)

R

(5) BV

42

E_COMP1_STAT

–

–

–

Elite Compressor #1 Output Status (0=output
is OFF, 1=output is ON)

R

(5) BV

43

E_LPS1

–

–

–

Elite Low Pressure Switch for Compressor
#1 Input Status (1=closed, 0=open/fault)

R

(5) BV

44

E_HPS1

–

–

–

Elite High Pressure Switch for Compressor
#1 Input Status (1=closed, 0=open/fault)

R

(5) BV

45

E_C1_OVRLOAD

–

–

–

Elite Compressor #1 Overload Switch Input
Status (1=closed, 0=open/fault)

R

(5) BV

46

E_COMP2_STAT

–

–

–

Elite Compressor #2 Output Status (0=output
is OFF, 1=output is ON)
