ASSEMBLY
6
TOOLS NEEDED: Phillips Head Screwdriver
1. Remove the heater body, two wheelbases, wheels, screws, and washers from the box. Remove the
packaging materials and keep for future storage.
2. Attach the wheels to each wheelbase with the supplied wheel screws, small black spring-washers, and
small grey washers.
3. Be certain the heater is unplugged and the controls are set to off. Set the heater on the floor upside
down.
4. Attach a wheel base (with wheels attached) to each end of the heater body using the supplied standard
screws, large black spring-washers, and large grey washers.
Wheel Screw
Wheel
Small Black Spring-Washer
Small Grey Washer
Wheel Base
Large Black Spring-Washer
Large Grey Washer
Standard Screw
Wheel Base
Heater Body
