SHARK SSG • 97-6134 • REV. 7/05a
27
PRESSURE W
ASHER
OPERA
T
OR’S MANU
AL
CONTROL PANEL PARTS LIST
ITEM PART NO. DESCRIPTION QTY
15 4-12806000 Nozzle, Red, 0°
(603537E/G)
1
4-12806015 Nozzle, Yellow, 15°
(603537E/G)
1
4-12806025 Nozzle, Green, 25°
(603537E/G)
1
4-12806040 Nozzle, White, 40°
(603537E/G)
1
16 11-0602 Decal, Stripe 1
17 11-1043 Label, Warning 1
18 10-9999 Lexan, Cover, Outdoor 1
19 10-08017 Label, Outdoor 1
20 70-180503 Screw, M4 x 10 4
21 2-30152 Valve, Metering 1
22 11-0711 Label, Metering Valve 1
23 4-02090000 Hose, Braided 2 ft.
24 2-9040 Clamp, Hose, UNI .46 - .54 3
25 4-02080000 Hose, Clear Vinyl 6 ft.
26 2-1905 Strainer, 1/4" Brass 1
27 90-017 ▲ Nut 10/32" 6
28 11-1042 ▲ Label, Ground 1
29 9.800-049.0 Label, Manufacturer's
Cleaning Solution
1
▲ Not Shown
ITEM PART NO. DESCRIPTION QTY
10 6-036711 Relay, 24VDC, 40 Amp
(503027E)
1
2-90220 ▲ Mounting Tape, Square
Backed 1
90-017 ▲ Nut 10/32 Keps 1
11 6-0611 Rectifier, Bridge (503027E) 1
90-1991 Screw, 10/32" x 1/2" BH SOC
Black
1
6-021595 Din Rail (12 VDC) 4"
12 95-07200008 Weldment, Control Panel,
Red
1
95-072000082 Weldment Control Panel,
Black 1
90-1994 ▲ Screw, Ground Post
10/32" x 1-1/4" 1
2-01411 ▲ Bushing, 1" Snap 1
13 11-1044 Decal, Operating Instructions 1
14 2-0103 Grommet, Rubber, Nozzle
Holder
4
15 4-12805000 Nozzle, Red, 0°
(503537E/G)
1
4-12805015 Nozzle, Yellow, 15°
(503537E/G)
1
4-12805025 Nozzle, Green, 25°
(503537E/G)
1
4-12805040 Nozzle, White, 40°
(503537E/G)
1
4-12805500 Nozzle, Red, 0° (503027E,
503027E/G )
1
4-12805515 Nozzle, Yellow, 15° (503027E,
503027E/G)
1
4-12805525 Nozzle, Green, 25° (503027E,
503027E/G)
1
4-12805540 Nozzle, White, 40° (503027E,
503027E/G)
1
