Warning – Spalding M5800142 User Manual
Page 10
10
ID# M5800142
01/07
5.
Rotate struts down and bend struts outward to line up with holes on base as shown. Secure
free ends of tank struts to tank with carriage bolt (8), and nut (20) as shown. Repeat for
other side.
17
22
1
17
21
5
10
Secure tank struts (21 & 22) to pole.
TIGHTEN BOLT (10) IN
LOCK NUT (5) UNTIL
FLUSH (EVEN) WITH
LOCK NUT’S OUTER
EDGE.
FAILURE TO FOLLOW
THIS WARNING COULD
RESULT IN SERIOUS
INJURY AND/OR
PROPERTY DAMAGE.
WARNING!
4.
8
20
17
8
20
17
