System Specifications
System Specifications
Frequency Response
20Hz to 20kHz + - 0.5 dB
Dynamic range
95 dBu, un-weighted, 22 Hz to 22 kHz
THD
0.008 % typ. @ +4 dBu, 1 kHz
Crosstalk
90dB 22 Hz to 22 kHz
Detector
RMS
Compressor Section
Compressor Section
Sensitivity
-10 dB to +20 dB
Ratio
variable (1:1 to 1 : )
Manual Attack Time
variable (0.3 ms / 20 dB to 300 ms / 20 dB)
Manual ReleaseTime
variable (0.05 to 5 Sec)
Output gain
variable (-20 to +20 dB)
Function Switches
ENHANCER
In/Out
I/O METER
Switches the Input/Output meter to read input or output level.
BYPASS
Switches the compression effect circuit in and out.
Operating Level (Rear Panel)
Changes the internal reference level from-4 dBu to -10 dBV.
Meters & LED's
Gain Reduction
6 segment LED display:
1/3/6/12/24/30 dB
Input/Output level
6 segment LED display:
OL/+6/0/-6/-18/-30 dB
Function switches
LED indicator in each
Audio Input
Audio Input
Connectors
1/4" TRS jack
Impedance
20k Ohm balanced, 10k Ohm unbalanced
Nominal Operating Level
Selectable +4dBu/-10 dBV
Max. Input Level
+21 dBu, balanced and unbalanced
CMRR
Typ. 40dB, >55dB @ 1kHz
Audio Output
Audio Output
Connectors
1/4" TRS jack
Impedance
60 Ohms balanced, 30 Ohms unbalanced
Max. Output Level
+21 dBu, balanced and unbalanced
Key Insert
Key Insert
Connector
1/4" TRS jack
Impedance
>10 k Ohm
Max. Input Level
+21 dBu
Power Supply
Power Supply
AC1800
USA/Canada
AC1800UK
U.K.
AC1800E
Europe
AC1800AU
Australia
Size
Dimensions
1.61" (41 mm)H x 8.67” (220.68 mm) x 7.5 (192 mm)
Weight
Weight
Net Weight
2.68 lbs (1.22 kg)
Shipping Weight
7.5 lbs (3.4 kgs)
