3. Als Versorgungsspannugen werden benötigt:
+5V æ 5% 0,65A
+12V æ 5% 0,45A (1,9A fur ca. 10 Sek. fur æ 10%)
4. Die Versorgungsspannung mub SELV entsprechen.
5. Alle Arbeiten auf dem Festplatte dürfen nur von Ausgebilde-
tem Servicepersonal durchgeführt werden. Bitte schaffen Sie
Festplatteetiketten nicht weg.
6. Der Einbau des Drives mub den Anforderungen gemäb DIN
IEC 950V DC 0805/05.90 entsprechen.
Configuring the drive
Required materials:
2-mm jumper connector (supplied as spare jumpers)
Your Seagate drive is configured for operation using the options
jumper block (J8) shown in Figure 1 on page 6. The settings for
the available configurations are shown in Figure 2 on page 7. The
options jumper block (J8) allows you to:
•
Set the SCSI ID
•
Connect a remote LED
•
Enable or disable parity
•
Enable or disable the drive’s terminator
•
Select the termination power source
SCSI ID settings. Each device on the SCSI bus must be as-
signed a unique SCSI ID. The drive uses pin-pairs 1 and 2, 3 and
4, and 5 and 6 on the options jumper block (J8) for assigning the
ID. The chart in Figure 2 shows you how to place the jumpers to
Medalist 1080sl SCSI Installation Guide, August 1995 5
