Appendix B: Connector Pinouts (continued)
Table 3b - XL 9000 DL to 25way ‘D’ Wiring: Channels 9-16 / 33-40 / 57-64 / 81-88
Signal Cable # Colour DL Audio DL Control 25wD Male
Pin Pin 9-12
Channel 9 Positive 3 Red 1 D1 2
Channel 9 Negative 3 Black 1 E1 15
Channel 9 Screen 3 Screen 1 F1 1
Channel 10 Positive 3 Red 2 D2 4
Channel 10 Negative 3 Black 2 E2 17
Channel 10 Screen 3 Screen 2 F2 14
Channel 11 Positive 3 Red 3 D3 7
Channel 11 Negative 3 Black 3 E3 20
Channel 11 Screen 3 Screen 3 G1 6
Channel 12 Positive 3 Red 4 D4 9
Channel 12 Negative 3 Black 4 E4 22
Channel 12 Screen 3 Screen 4 G2 19
Channel 9 Gain control 3 Red 5 D1 3
Channel 9 Switch Control 3 Black 5 E1 16
Channel 10 Gain control 3 Red 6 D2 5
Channel 10 Switch Control 3 Black 6 E2 18
Channel 11 Gain control 3 Red 7 D3 8
Channel 11 Switch Control 3 Black 7 E3 21
Channel 12 Gain control 3 Red 8 D4 10
Channel 12 Switch Control 3 Black 8 E4 23
ID Bit 1 3 Screen 5 F1 11*
ID Bit 2 3 Screen 6 F2 24*
ID Bit 3 3 Screen 7 G1 n/c
ID Bit 4 3 Screen 8 G2 n/c
ID Bit 5 n/c
Signal Cable # Colour DL Audio DL Control 25wD Male
Pin Pin 13-16
Channel 13 Positive 4 Red 1 D5 2
Channel 13 Negative 4 Black 1 E5 15
Channel 13 Screen 4 Screen 1 G7 1
Channel 14 Positive 4 Red 2 D6 4
Channel 14 Negative 4 Black 2 E6 17
Channel 14 Screen 4 Screen 2 G8 14
Channel 15 Positive 4 Red 3 D7 7
Channel 15 Negative 4 Black 3 E7 20
Channel 15 Screen 4 Screen 3 F7 6
Channel 16 Positive 4 Red 4 D8 9
Channel 16 Negative 4 Black 4 E8 22
Channel 16 Screen 4 Screen 4 F8 19
Channel 13 Gain control 4 Red 5 D5 3
Channel 13 Switch Control 4 Black 5 E5 16
Channel 14 Gain control 4 Red 6 D6 5
Channel 14 Switch Control 4 Black 6 E6 18
Channel 15 Gain control 4 Red 7 D7 8
Channel 15 Switch Control 4 Black 7 E7 21
Channel 16 Gain control 4 Red 8 D8 10
Channel 16 Switch Control 4 Black 8 E8 23
ID Bit 1 4 Screen 5 G7 n/c
ID Bit 2 4 Screen 6 G8 n/c
ID Bit 3 4 Screen 7 F7 12*
ID Bit 4 4 Screen 8 F8 n/c
ID Bit 5 n/c
* Pinout shown is for channels 1-24. For other bays connect id. bits as shown in Table 4.
