CDX-GT240
CD Receiver MP3/WMA Player
Please visit the Dealer Source for current information at
www.sony.com/dealersource
Features
MP3/WMA Playback MP3/WMA Playback : Play CDs, CD-Rs,
and CD-RWs, including discs loaded with MP3s and WMA files. 1 1
Detachable faceplate with front panel aux in The front
auxiliary input lets you connect almost any portable audio
device to your car's sound system.
Black 13 segment LED display 13 Segment black LCD with
negative display for viewing information.
EQ3 Stage 2 and 52 Watts x 4 High Power The GT240 delivers
52 watts of peak power to all four speakers for increased sound
levels (208 watts total power).
Rear/Sub selectable pre amp output with LPF/HPF Boost your
car's sound system with minimal effort and maximum flexibility
by using the pre-out to add a subwoofer and external amplifier,
or another audio component, to your Xplod® system. A built-in
LPF (Low Pass Filter) and HPF (High Pass Filter) work to deliver
overall better sound, and the LPF features a phase shift
function that reduces low-end reverberation.
Radio Data System (RDS) Radio Data System (RDS) feature
displays radio broadcast information such as artist, title, and
album when listening to compatible AM/FM stations.
Red key illumination
Specifications
Audio Features
Level Control: -8dB ∼ +18dB on front aux input
Convenience Features
CD Text Display: CD and MP3 / WMA data displayed
On-Screen Clock: 12H
Key Illumination: Red
General
Disc Capacity: 1
Color: Gun Metallic / Black
Audio
Preout Impedance: 220 ohms
Preout Voltage: 2 volt
Frequency Response: CD: 10-20,000 Hz
Wow and Flutter: Below measurable limit
Station Preset(s): 18 FM / 12 AM
Digital-to-Analog Converter: 24bit
Tuner Frequency Range: FM:Tuner Frequency Range(MHz): 87.5-
107.9, AM:Tuner Frequency Range(kHz): 530-1710
Tone Control(s): Low +/- 10 dB at 60 Hz
Mid +/- 10 dB at 1 kHz
High +/- 10dB at 10 kHz
Tuner Type: SSIR-EXA with RDS
Volume Control: Tel/Nav Attenuation Circuitry
CD Playback: CD, CD-R / CD-RW (MP3/WMAfiles)
Band: AM / FM
Signal-to-Noise Ratio (dB): CD: 120 dB
Convenience
Tilt Range: 0-45° mounting angle
Amplifier Section
Speaker Impedance: 4-8 Ohms
Max power output: 52 watts x 4 at 4 ohms
Tuner
FM Usable Sensitivity: 10 dBf
Selectivity: 75 dB at 400 kHz
S/N Ratio: 70 dB (mono)
Frequency Response: FM: 20-15,000 Hz
Stereo Separation: 40 dB at 1 KHz
Power
Power Consumption (in Operation): 45w
Output Power: 52W x4 High Power - 17 watts per channel
minimum continuous average power into 4 Ohms, 4 channels
driven from 20 Hz to 20 kHz with no more than 5% total
harmonic distortion.
Current Drain: 3 - 5 amps
Input Power: 12 V DC car battery (negative ground (earth))
Input Voltage: 12 V DC car battery (negative ground)
Inputs and Outputs
RCA Audio Output(s): Front and Rear/Sub selectable RCA pre-
amp outputs
Antenna Terminal(s): Aerial Input Terminal
12V Trigger Output(s): Power antenna
Amplifier turn on
Audio In: Front Aux input with variable level: -8dB ∼ +18dB
Infrared Port: Wireless remote
Dimensions
Weight: 1.2Kg
Measurements: 178 x 50 x 179mm
Supplied Accessories
Parts for installation and connections (1 set)
Optional Accessories
RM-X114 wireless remote
Color: Gun Metallic / Black
UPC Code: 027242774049
1.Not all MP3, WMA, AAC files may playback due to file variations. Copyright protected ACC-LC files cannot
be played back.
