ScyTek Electronics VISIONGUARD 8000 - Manual (Page 29)

VisionGaurd 8000 - Page 25
Wiring Diagrams
TO POSITIVE
DOME LIGHT
+12V
Black/White
(-) DOME LIGHT
OUTPUT
TO NEGATIVE
DOME LIGHT
+12V
Black/White
(-) DOME LIGHT
OUTPUT
Positive Dome Light Negative Dome Light
TO POSITIVE
HORN WIRE
+12V
Brown/White
(-) HORN OUTPUT
TO NEGATIVE
HORN WIRE
+12V
Brown/White
(-) HORN OUTPUT
Positive Horn Honk Negative Horn Honk
Blue/Yellow Wire
(+) GLOW PLUG
INPUT
Yellow Wire
(+) IGNITION
(-) GLOW PLUG
WIRE FROM
VEHICLE
+12V
Yellow Wire
(+) IGNITION
Violet Wire
(+) STARTER
TO STARTER
IGNITION SWITCH
Orange wire
(-) ANTIGRIND/
STARTER DEFEAT
AC
C
LO
CK
ON
ST
A
R
T
Negative Glow Plug Starter Defeat/Anti-Grind
