3 Step Installation
Step 1 : Mount LCD to dash
Step 2 : Connect LCD power wire to reversing light fuse
Step 3 : Run cable & mount camera to back of the car
Wired Vehicle Reversing System
LCD Monitor & Wide Angle Camera
Safeguard family, pedestrians & protect your vehicle with this easy,
do-it-yourself wired video vehicle safety system!
www.swannsecurity.com
™
Please note that the information contained within this document is subject to change without notification.
warranty
MONTHS 12
™
™ Advanced security made easy
plug&play security
Product Specifi cations
Video
Image Sensor 1/3” CMOS
Video Quality 330 TV Lines
Viewing Angle 90 degrees
Day/Night Mode Color during day /
switches to B&W at night
Display Resolution 480 x 234
Display Size & Type 2.4” LCD
Video Inputs 1 RCA
Night Vision
Night Vision Distance Up to 9ft / 3m
General
Operating Power DC 12V
Operating Temperature 32°F ~ 122°F / 0°C ~ 50°C
Dimensions Monitor
3.2” x 2.5” x 1.8” / 82mm x 63 x 45mm
Dimensions Camera 1.9” x 1.8” x 1.3” / 48mm x 46mm x 32mm
Weight Monitor 5.4oz / 153g (with bracket)
Weight Camera 2.3oz / 66g
Cable Length 19ft / 6m (camera)
6ft / 2m (monitor)
Package Contents:
• Wired Camera
• 2.4” LCD screen
• Windscreen bracket
• Cigarette lighter adaptor
• Operating Instruction
This product will be set to the TV standard of the country of sale
