SIIG TV Mount User Manual
Page 2
1
2
3
1
2
1
IMPORTANT: If you don't understand the installation instructions, please consult an
installation specialist
Maintenance
Place your TV screen down on a soft, flat surface, and locate the threaded
mounting points that are located on the back of the display.
According to the size of the display's hole, choose the corresponding screw (E/F/G)
and small washer (C) and insert into the hole as shown (figure 2-a) and tighten.
Concrete/Brick Wall Installation
Step 2: Display Plate Installation
Position the Wall Plate onto the wall again and insert the bolts (A) and large
washer (D) into the anchor as shown (figure 1-b) and tighten.
Pre-drill four holes at the positions you've marked and insert one concrete anchor
(B) into each hole.
Place the wall plate against the wall and mark four locations to be used for
mounting the wall plate.
Step 3: Final Installation
Check the mounting screws every two months for tightness.
Hang the display plate onto the top of the
wall plate and slide it onto the wall plate as
shown (figure 3-a).
