a 4 hour timed start interval. The lights will flash and the siren will chirp 2X or 4X dependant upon 2 or 4 hour
interval setting.
NOTE: Once selected, 2 or 4, this timer interval will remain in memory until it is manually changed. To
change, the above sequence will have to be followed.
TIMED START OPERATION:
To begin the start timer, within 10 seconds of turning off the ignition switch, activate the RF command to
start 2 times. (Press the trunk/key button four times). The lights will flash and the siren will chirp 4 times.
Indicating timed interval mode has been initiated. The vehicle will automatically start every 2 or 4 hours as
programmed. To cancel the timed start mode start the vehicle either by RF or by the ignition key.
REMOTE START SELECTABLE FEATURES
Feature LtsFlash 1X Lts Flash 2X Lts Flash 3X Lts Flash 4X Default LED Pattern
1 RF Start Chirp Off On On 1X Pause,etc...
2 Run Time 5 Min. 10 Min. 15Min. 20 Min. 10 Min 2X Pause,etc...
3 Park Lights On Steady Flash Steady 3X Pause,etc...
4 Input Check NA Tach Tach 4X Pause,etc...
5 NA NA NA NA 5X Pause,etc...
6 Ign. 2 Crank Off On On 6X Pause,etc...
7 Diagnostics Off On Off 7X Pause,etc...
8 NA NA NA NA NA NA 8X Pause,etc...
9 Gas/Diesel Gas Diesel 10 Diesel 15 Diesel 20 Gas 9X Pause,etc...
NOTE: When selecting Diesel operation, (Feature Nine), over gasoline, the only change is to the ignition
circuits. When Diesel is selected, the ignition circuits will power up 10, 15, or 20 seconds before
the start circuit. The intent of this feature is to allow the glow plug warming required by some diesel
engines. If your vehicle is a instant start diesel, it is not necessary to activate this feature.
NOTE: When selecting Diesel mode, be certain that the intended vehicle has a true tach reference and be
certain to connect the tach input wire.
To Program The Remote Start Selectable Features:
1. Turn the ignition key to the On position.
2. Press and release the valet/program switch three times.
3. Immediately turn the ignition key Off then press transmitter trunk/key button for 1 second.
4. Immediately turn the ignition key back On.
5. Press and release the valet/program switch two times. The siren will emit 2 short and 1 long chirp
verifying you are in the feature program mode.
6. Use channel 1 button on the transmitter to advance to the feature you want to change. EXAMPLE- If you
need to change selectable feature 3, press and release channel 1 button on the transmitter 3 times in
succession. The parking lights will flash, and the siren will chirp 3 times confirming that selected feature
3 can be changed.
7. Use the trunk/key button on the transmitter to change the selection of the programmable feature. If you
are not sure what the setting for any feature is, press the trunk/key button one time, the parking lights
will flash one, two, three or four times indicating the features setting.
NOTE: Once you've entered the program mode DO NOT allow more than 15 seconds to pass between
steps, or the programming mode will be terminated.
Programming Tach Rate:
NOTE: All applications require that tach be programmed.
The unit will not operate unless tach is programmed. If an attempt is made to start the vehicle via the remote
start without first programming tach, the unit will flash the parking lights 7 times indicating tach has not been
learned and stored. If the tach rate is not properly programmed to the specific vehicle, the unit may not realize
that the vehicle is running in certain instances reengage the starter motor.
18
