Page 2
Installation:
1. Chose a suitable location. Usually, the higher up a dummy camera is, the more authentic
it will appear.
2. Plug the optional AC power adapter into a power outlet, and run the adapter’s wire to where the
dummy camera will be mounted.
NOTE 1 - For a more professional and realistic appearancel, run the adapter’s wire through the
wall so the wire is hidden.
NOTE 2 - The battery compartment is not used. Do not install battery in the battery compartment.
3. Screw the mounting bracket into the bottom of the dummy camera.
4. Connect the adapter’s wire to the power connector of the dummy camera.
5. Hide the dummy camera’s BNC connector so no one can see that it is not connected to a
monitor.
NOTE - BNC connector is not used. For looks only.
6. Mount the bracket’s base to the wall, using the three included mounting screws. If the wall is
made of dry wall, brick, or similar material, it may be necessary to use the included plastic
screw anchors.
7. Do a final test of the dummy camera with the lights turned on and turned off.
VD-10BN -- Dummy Security Camera
VD-30BS -- Dummy IR Bullet Camera (non-working IR)
VD-20NN -- Dummy Dome Camera
VB-HC1 -- Ceiling mount bracket for PTZ Speed Dome
VD-40BN -- Dummy PTZ Speed Dome Camera
Page 3
Model # and Description
How It Works
The SECO-LARM VD-10PL dummy camera is a great low-cost way to deter crime at home, in an
office, a parking lot, and around playgrounds. The dummy camera creates the perception of
electronic surveillance without the high cost, high maintenance, and upkeep of real CCTV
cameras, monitors and DVR's.
Unlike most dummy cameras, the IR LEDs of the VD-10PL turn on automatically when it is dark or
when the lights are turned off, and turn off when it is light or the lights are turned on.
Criminals are more likely to move on to an easier target if they know their activities may be
recorded.
Mix dummy cameras with real cameras to make the dummy cameras more believable.
• Incorporates a realistic camera with
video/power cables (one cable) to
give it an authentic look.
• Metal mounting bracket included.
• Incorporates a realistic camera module to give it an authentic look.
• Constructed of strong ABS plastic.
• Incorporates a realistic camera with
a battery-powered LED to give it an
authentic look.
• Includes simulated Video and power
cable.
• Incorporates a realistic camera with a
battery-powered LED to give it an
authentic look.
• Indoor / outdoor use.
• Weatherproof ABS plastic housing.
• For model VD-40BN PTZ speed dome.
• 9" pipe with hole for easy access to wires.
• Threaded conduit fittings.
Check out SECO-LARM’s full line of dummy cameras.
• Single flashing battery-powered LED.
• Requires 2 AA batteries (not included).
• Constructed of strong ABS plastic.
• Indoor / outdoor use.
• Metal mounting bracket included.
• Requires 2 AA batteries (not included).
• Constructed of weatherproof aluminum
metal housing.
• Metal wall mount bracket included.
• Requires 2 AA batteries (not included).
• Threaded conduit fittings allow for
extended mounting.
VD-10PL -- Dummy IR Bullet Camera with real working IR LEDs
• Includes dummy camera module
with real working IR LEDs.
• Metal mounting bracket included.
• Constructed of strong ABS plastic.
VD-10BNA -- Dummy Box Camera
• Incorporates a realistic camera with video/power cables
(one cable) to give it an authentic look.
• Battery-powered LED.
• Requires 2 AAA batteries (not included).
• Constructed of strong ABS plastic.
