Jura Capresso Impressa 68193 User Manual
Page 5
SELECT
PRODUCT
A
B
C
D
FIG. 2
FIG. 3
FIG. 3A
Display Dialog System
ON/OFF Button
1-CUP Espresso Button
1-CUP Coffee Button
RINSE Button
2-CUP Espresso Button
2-CUP Coffee Button
3.1 Hot Water Portion symbol
3.2 Milk Portion symbol
3.3 Selector Dial with push button
3.4 Hot Water symbol
3.5 Milk symbol
3.6 Cappuccino button
3.7 Latte Macchiato button
FIG. 4
A La Carte Button
Ground Coffee Button
Rotary Dial w/push button
Service Cover
(do not remove)
N
O
P
Q
E
F
G
A.
B.
C.
D.
E.
F.
G.
N.
O.
P.
Q.
C O F F E E
R E A D Y
Operating Display
Auto Cappuccino System
5.
3.1
3.3
3.4
3.6
3.2
3.5
3.7
Dual
Coffee
Spouts
Hot
Water
Spout
