HD200 and HD300 Sprayers
Booms
Construction Heavy-duty 14-gauge square tube construction
Number of sections 3
Breakaway Bi-directional (forward and backward)
Boom height Adjustable
Lift system Electro-hydraulic; standard
Width 18 ft. (5.5 m) or 15 ft. (4.6 m) / 21 ft. (6.4 m)
Nozzle confi guration Triple Nozzle bodies on 20-in. (50.8 cm) spacing
Foam Marker
Type Electric
Pump Individual air and liquid pump, solution mixes at foamer head
Rate Adjustable with no tools by turning rotary knob on foamer box
Mounting
Type 3-pin sprayer to ProGator frame
Removal 3-pins, disconnect 3 electrical connectors, and 2 hydraulic lines for easy removal without tools
Storage Optional storage stands
Dimensions (18-ft. boom)
Boom height (wings raised) 96 in. (244 cm)
Boom width (wings raised) 66 in. (167 cm)
Boom width (wings lowered) 203 in. (514 cm)
Dimensions (15/21-ft. boom)
Boom height (wings raised and extensions folded) 70 in. (178 cm)
Boom width (wings raised and extensions folded) 96 in. (244 cm)
Boom width (wings raised) 91 in. (231 cm)
Boom width (wings lowered and extensions folded) 188 in. (478 cm)
Boom width (wings lowered and extensions extended) 242 in. (615 cm)
to
er
nnect
h stor-
have to
ls so
.
WITH DUAL-LEAF SPRINGS,
IT CAN CARRY AN OCEAN.
ProGator Heavy-Duty Utility Vehicle Series. With a
heavy-duty suspension with dual-leaf springs and
one-piece rear axle it can shoulder a sprayer tank.
And much, much more.
2020A & 2030A ProGators
• Seamless shifting on the go with 5-speed
synchomesh transmissions
• Optional on-demand or automatic 4WD
• Tight turning radius 18 inches (2WD), 69 inches (4WD)
• 19.1 mph (30.7 km/hr)
• 879 cc on 2020A, 1115 cc diesel engine on 2030A
• Rated capacity 2,600 lb. (1182 kg)*
* Including 200-lb. operator, 200-lb. passenger, & loaded
attachment. 2,610 lb. on 2030A, 2,650 lb. on 2020A.
