68
English
Video
Video Input Sensitivity/Impedance ..................... Composite video: TV SOUND/DBS, VCR1, VCR2, VIDEO, DVD
...................................................... 1 Vp-p/75 ohms
S-video: TV SOUND/DBS, VCR1, VIDEO, DVD
(Y: luminance): ........................................................ 1 Vp-p/75 ohms
(C: chrominance, burst): .......................................... 0.286 Vp-p/75 ohms
Video Output Level ............................................. Composite video: VCR1, VCR2, MONITOR OUT ... 1 Vp-p/75 ohms
S-video: VCR1, MONITOR OUT .............................. 1 Vp-p/75 ohms
(Y: luminance): ........................................................ 1 Vp-p/75 ohms
(C: chrominance, burst): .......................................... 0.286 Vp-p/75 ohms
Synchronization .......................................................................................................................................... Negative
Signal-to-Noise Ratio ................................................................................................................................. 45 dB
On-Screen Color System ............................................................................................................................ PAL
FM tuner (IHF)
Tuning Range ............................................................................................................................................. 87.5 MHz to 108.0 MHz
Usable Sensitivity ................................................ Monaural ..................................................................... 12.7 dBf (1.2 µV/75 ohms)
50 dB Quieting Sensitivity .................................. Monaural ..................................................................... 16.3 dBf (1.8 µV/75 ohms)
Stereo .......................................................................... 38.3 dBf (22.5 µV/75 ohms)
Signal-to-Noise Ratio (IHF-A weighted) ............ Monaural ..................................................................... 80 dB at 85 dBf
Stereo .......................................................................... 73 dB at 85 dBf
Total Harmonic Distortion .................................. Monaural ..................................................................... 0.15 % at 1 kHz
Stereo .......................................................................... 0.2 % at 1 kHz
Stereo Separation at REC OUT .................................................................................................................. 40 dB at 1 kHz
Capture Ratio .............................................................................................................................................. 1.5 dB at 85 dBf
Alternate Channel Selectivity ..................................................................................................................... 60 dB: (±400 kHz)
Frequency Response ................................................................................................................................... 30 Hz to 15 kHz: (+0.5 dB, –3 dB)
AM tuner
Tuning Range ............................................................................................................................................. 531 kHz to 1,602 kHz (at 9 kHz
interval)
530 kHz to 1,600 kHz (at 10 kHz
interval)
Usable Sensitivity ................................................ Loop antenna ............................................................... 300 µV/m
Signal-to-Noise Ratio ................................................................................................................................. 50 dB (100 mV/m)
General
Power Requirements ................................................................................................................................... AC 110/127/220/230–240V ,
adjustable with the voltage selector,
50/60 Hz
Power Consumption ................................................................................................................................... 280 watts
2 watts (in standby mode)
Dimensions (W x H x D) ............................................................................................................................ 435 x 157 x 412.5 mm
(17
3
/
16
x 6
3
/
16
x 16
1
/
4
inches)
Mass ............................................................................................................................................................ 11.3 kg (25.0 lbs)
Designs & specifications are subject to change without notice.
