34
INDEX (cont.)
FRONT VIEW
VIDEO (MONO) L–AUDIO–R
POWER
MENU POWER TIMER REC MTS
OK
REC
q
PLAY REW
2
FF
3
PAUSE
6
STOP/EJECT
5 / 8
TV/VIDEO
CH
1
6 9 0 ! @ # $
2 3 4 5
7 8
1 Power ON/OFF Button (
੬
pg. 7)
2 Cassette Loading Slot
3 Rewind Button (
੬
pg. 12)
Reverse Search Button (
੬
pg. 14)
4 Play Button (
੬
pg. 12)
5 Fast-Forward Button (
੬
pg. 12)
Forward Search Button (
੬
pg. 14)
6 Video and Audio Input Connectors (
੬
pg. 27)
* The HR-A32U has only one Audio input
connector.
7 Menu Button (
੬
pg. 7)
8 Front Panel Indicators (
੬
pg. 35)
9 Remote Control Sensor
0 Channel
5∞ Buttons ( ੬
pg. 7)
! OK Button (
੬
pg. 7)
@ Record Button (
੬
pg. 13)
# Stop/Eject Button (
੬
pg. 12)
$ Pause Button (
੬
pg. 13)
REAR VIEW
1 Power Cord (
੬
pg. 6)
2 Video and Audio Output Connectors (
੬
pg. 6)
* The HR-A32U has only one Audio output
connector.
3 ANT. IN Connector (
੬
pg. 6)
4 Channel 3/4 Switch (
੬
pg. 6)
5 RF OUT Connector (
੬
pg. 6)
ANT. IN
RF OUT
OUT
CH3 CH4
AUDIO
R
L
VIDEO
1 2 3
5 4
