9.2 Spa Features And Controls

1

4

2

2

4

4

7

5

9

8

10

3

. Control Panel
2. Air Controls
3. Filter/Skimmer
4. Therapy Jets
5. Massage Selector (J-220 only).

J-20 models use a “Divert-A-Jet”
which functions as a diverter in
these models. See page 9 for
details.

6. Therapy Seats

7. Spa Light
8. Vertical Jets (Foot Jets)
9. Footwell Suction Fitting &

Filter.

0. Heater Return/Gravity Drain

Fitting

. Calf Jets (J-220 only)

J-220 model illustrated - Location of Features Vary by Model
