RJ-11 Straight
This table lists the required pins used in the Modem cable used to connect the Gateways
to an asynchronous modem. Pins should be connected from one RJ-11 connector to the
other without transpositions or other wiring changes.
Units Supported
• C21
JBM Electronics Part Number: N/A
RJ-11 MODEM CABLE
PIN
DESCRIPTION
1
Unused
2
Tip
4
Ring
5
Unused
Used for connecting a modem to the C21
