JBL GTO14001 User Manual
Page 13
Qty Part Number
Reference Designator
Description
MISCELLANEOUS/MECHANICAL
16 LS1JM0401401
Screw, BM4*14Black zinc
plating
For power transistor
4
LS1JT0301201
Screw, BT3*12Black zinc
plating
For PCB board
1
LS1JT0301001
Screw, BT3*10Black zinc
plating
For RCA terminal
4
ZL-10038A-15
Standoff
φ4.9*φ7.2*7.0mm Nylon 66
5
DQ8069032084
Washer
Φ6.9*Φ3.2*0.8MM M3, For Logo house PCB board
1
JY264A22A01X
MICA
64*22*0.1MM Ф4.5MM 16.5MM 7MM
1
PL-E0011-150
Light diffusion paper
64.0*41.0*0.1MM two sides with glud
1
XG-0033-0501
Bottom plate
234.0*439.2*1.2MM 1.2MM black painting
1
JY247A22A01X
MICA
47*22*0.1MM Φ4.5mm 16.5mm 7mm
4
LS1AA0404501
Screw
PA4*45 black Zinc plating
1
MP-O752-3001
Logo plate
43.73*35.94*2.0MM Alum. Plate with stamped JBL
logo, brushed mental surface on the plate, diamond cut
on JBL logo. With one side glue. Durable by 95 ~ -35 ℃
2
GD-600030003
Reflector board 1
175.0*6.0*2.0MM PC Clear silkscreen
1
GD-600040003
Reflector board 2
64.0*41.0*2.0MM PC Clear silkscreen
16 JY217A12A10A
Pottery
17*12*1.0mm White
2
LS1FJ0200801
Screw
KA2*8 black Zinc
2
LS1CA0301501
Screw
TA3*15 black Zinc
1
LS1AM0300601
Screw
PM3*6 SWC black Zinc, temperature switch
4
XN-10500-012
Knob, Controls
ABS-757 black Ф10.5*9MM with white arrow
4
JY442A24A05X
Insulated paper
ф42.0*ф24.0*0.5MM red one sided glued,inductor
1
24T1-012800B J2
Jumper
128.00*21.00*1.50MM, yellow copper
3
PL-G0003-000 J3 J4 J5
HA604 Jumper
95*20.7*1.5mm T=1.5mm
2
PL-E0017-150
Light diffusion paper
175.0*6.5*0.1 ends with 3m
1
JY432A13A10X
Insulated paper
32.0*13.0*1.0 red with one sided glued,For E-cap
1
JY440A20A05X
Insulated paper
40.0*20.0*0.5 red with one sided 3M, For E-cap
2
PL-A0051-000
Transistor Clamp
14.0*7.0*30.0 with red isulated paper (30.0*10.0*1.0)
4
PL-A0054-000
Transistor Clamp
14.0*7.0*64.0 with red isulated paper (64.0*10.0*1.0)
1
PL-A0055-000
Transistor Clamp
14.0*7.0*45.0 with red isulated paper (45.0*10.0*1.0)
4
LS1CM0300501
Insulated paper
TM3*5 black Zinc
12
GTO14001
