Specifications shown are for SP mode unless otherwise specified.
Design and specifications subject to change without notice.
Specifications
GENERAL
Power requirement
Rating : AC 110 V – 240 V d , 50 Hz/60 Hz
Operating : AC 90 V – 260 V d , 50 Hz/60 Hz
Power consumption
Power on : 18 W
Power off : 3.5 W
Temperature
Operating : 5°C to 40°C
Storage : –20°C to 60°C
Operating position : Horizontal only
Dimensions (W x H x D) : 400 mm x 94 mm x 265 mm
Weight
: 3.0 kg
Format : S-VHS/VHS standard
Maximum recording time
(SP) : 240 min. with E-240 video cassette
(PAL/MESECAM)
: 160 min. with T-160 video cassette
(NTSC)
(LP) : 480 min. with E-240 video cassette
(PAL/MESECAM)
(EP) : 720 min. with E-240 video cassette
(PAL/MESECAM)
: 480 min. with T-160 video cassette
(NTSC)
VIDEO/AUDIO
Signal system : PAL-type colour signal and CCIR
monochrome signal, 625 lines/
50 fields
: NTSC colour and EIA monochrome
signals, 525 lines/60 fields
Recording system : DA-4 (Double Azimuth) head helical
scan system
Signal-to-noise ratio : 45 dB
Horizontal resolution
S-VHS : 400 lines
VHS PAL/MESECAM : 250 lines
VHS NTSC
: 220 lines
Frequency range
Normal audio : 70 Hz to 10,000 Hz
Hi-Fi audio : 20 Hz to 20,000 Hz
Input/Output : RCA connectors:
IN x 2, OUT x 1
S-Video connectors:
IN x 2, OUT x 1
TUNER/TIMER
TV channel storage
capacity : 99 positions (+AUX position)
Tuning system : Frequency synthesized tuner
Channel coverage
VHF : (Low) 42 MHz – 175 MHz/
(High) 175 MHz – 470 MHz
UHF : 470 MHz – 870 MHz
Aerial output : UHF channels (Adjustable E28 – E60)
Memory backup time : Approx. 6 months
Estimated figure based on supplied
fresh battery; actual performance may
differ.
ACCESSORIES
Provided accessories : RF cable,
S-Video cable,
Infrared remote control unit,
“R6/UM-3” battery x 2,
Lithium battery – CR2025 –
