JVC GR-AX937 - Manual (Page 13)

EN
13
Grip Adjustment
EXPAND LOOP
1
Separate the Velcro strip.
INSERT HAND
2 Pass your right hand through the loop and grasp the
grip.
ADJUST STRAP LENGTH
3
Adjust so your thumb and fingers can easily operate
the Recording Start/Stop button and Power Zoom
lever. Refasten the Velcro strip.
Shoulder Strap Attachment
ATTACH STRAP
1
Following the illustration at left, thread the strap
through the top of the eyelet
1 , then fold it back
and thread it through the keeper 2 , and then
through the buckle 3 . Repeat the procedure to
attach the other end of the strap to the other eyelet,
making sure the strap isn’t twisted.
ADJUST LENGTH
2 Adjust as shown in the illustration at left 1 , then
slide both keepers snug against the eyelets to
prevent slipping
2 .
Tripod Mounting
ALIGN AND TIGHTEN
1 Align the screw and camera direction stud on the
tripod with the camera’s mounting socket and stud
hole. Then tighten the screw.
2
3
1
2
1
Recording Start/Stop button
