EN
31
ENTREE ANT. IN
ENTREE/DECODEUR
IN/DECODER AV2 ENTREE/SORTIE
IN/OUT
SORTIE
RF OUT ANTENNE AV1
ENTREE ANT. IN
ENTREE/DECODEUR
IN/DECODER AV2 ENTREE/SORTIE
IN/OUT
SORTIE
RF OUT ANTENNE AV1
Another recorder
RF Cable
(provided)
Another recorder
Recorder
21-pin SCART Cable
(not provided)
Player Your recorder Recorder Your recorder TV Receiver TV Receiver
RF Cable
(provided)
21-pin SCART Cable
(not provided)
Player
VIDEO
CHAN-
NEL or
AV mode
VIDEO
CHANNEL
or AV
mode
AV2 SELECT Setting
1 Press MENU to access the Main Menu screen.
2 Press %fi to move the highlight bar (pointer) to "MODE SET", then press OK or #
.
3 Press %fi to move the highlight bar (pointer) to "AV2 SELECT".
4 Press OK or
#
to select "AV2", "DECODER" or "SAT".
a–AV2 : To use this recorder as the recording deck with the player connected to the
AV2 IN/DECODER connector, or to use the satellite tuner connected to the
AV2 IN/DECODER connector.
b–DECODER : To use a decoder connected to the AV2 IN/DECODER connector.
c–SAT
: To view a satellite programme with the TV set while the recorder is in Timer
mode, in Stop mode, recording or turned off. (
੬
pg. 32)
5 Press MENU to return to normal screen.
● If you have a decoder connected to the AV2 IN/DECODER connector, be sure to set "AV2 SELECT" back to "DECODER" after
editing.
● If you're not connecting a decoder to the AV2 IN/DECODER connector, leave "AV2 SELECT" set to "AV2".
● The default setting is "AV2"; if the recorder's memory backup has expired due to a power cut or because the AC was
removed from the recorder, "AV2" will be automatically selected when the power is restored to the recorder. If you are using
a decoder, be sure to set "AV2 SELECT" back to "DECODER".
MODE SET
B. E. S. T. ON
PICTURE CONTROL AUTO
AUTO TIMER OFF
O. S. D. ON
DIRECT REC ON
POWER SAVE ON
AV2 SELECT AV2
NEXT PAGE
[ 5∞] =
[MENU] : EXIT
