JCDWIN
6
Display Selector (DISP)
This unit can display either the clock time or radio frequency/CD player functions. Press the
DISP button (6) on the control panel or remote control to display the time for approximately 5
seconds. The correct time of day can be set by pressing and holding the DISP button.
Setting the Clock
To set the clock, perform the following steps:
1.
Press the DISP button (6) to display the clock.
2.
Press and hold the DISP button (6) until the time display flashes.
3.
Within 5 seconds, press the TUNE down button (18) to adjust the minutes to the desired
setting.
4.
Press the TUNE up button (19) to adjust the hour.
5.
Press the DISP button again to return to radio frequency or disc play or wait five seconds
and normal operation will resume automatically.
Preset Equalizer (PEQ)
The preset equalizer applies preset sound effects to the unit’s audio output signal. To adjust
the preset equalizer, press the PEQ button (23) on the remote control. Press repeatedly to
choose between the following modes: “FLAT”, “CLASSICS”, “POP M”, “ROCK M” or “DSP
OFF”.
TUNER OPERATION
Select a Band
Press the BAND button (21) on the control panel (or BND on the remote control) to change
between three FM bands and one AM band. Each band stores up to six preset stations.
Tuning
Auto Seek Tuning
Press the TUNE up (19) or TUNE down button (18) on the control panel (or U and D on the
remote control) for less than three seconds to move to the next station automatically.
Manual Tuning
Press the TUNE up (19) or TUNE down button (18) for more than three seconds to enter
manual tuning mode. Press the TUNE up or TUNE down button to change the radio frequency
number up or down one step.
Scan
Press the SCAN button (22) on the control panel (or SCN on the remote control) to
automatically search for stations. Each available station will flash on the display for a few
seconds before the next is searched. To select a “flashing” station, press the SCAN button
again.
Preset Stations
Six numbered preset buttons store and recall stations for each band.
Store a Station
Select a band (if needed), then select a station. Hold a preset button (9-14) for three seconds.
The preset number will appear in the display.
Recall a Station
Select a band (if needed). Press a preset button (9-14) to select the corresponding stored
station.
1
4
6
5
2
3
8
10
16
9
11
12
13
14
21
15
20
19
18
7
22
17
