JBL T696 User Manual

T696 limited

Declaration of Conformity

We, Harman Consumer Group, Inc.

2, route de T ours

72500 Château du Loir

France

declare in own responsibility that the product described in this owner’s manual is in

compliance with technical standards:

EN 61000-6-3:2001

EN 61000-6-1:2001

Klaus Lebherz

Harman Consumer Group, Inc.

Château du Loir, France 6/08

Designed and engineered in the USA.

Avalid serial number is required for warranty coverage.

Features, specifications and appearance are subject to change without notice.

This product is designed for mobile applications and is not intended for connection to the mains.

Harman Consumer Group, Inc. • 250 Crossways Park Drive, Woodbury

, NY 11797 USA • www.jbl.com

JBL is a trademark of Harman International Industries, Incorporated, registered in the United States

and/or other countries.

www .jbl.com

6-5/8"

167mm

4-7/16"

112mm

10-5/8"

270mm

4-5/8"

117mm

204mm

153mm

4-13/16"

121mm

8-3/4"

223mm

3-3/16"

81mm

1-1/2"

39mm

SPECIFICATIONS

Impedance:

4 Ohms

Power Handling, RMS:

150W

Power Handling, Peak:

600W

Frequency Response:

35Hz – 20kHz

Sensitivity (2.83V, 1m):

93dB

GENERAL CARE

The loudspeaker grilles may be cleaned with a damp cloth.

Do not use any cleaners or solvents on the grilles or the speaker cones.

WARRANTY

The T696L is warranted against defects. The duration of the speaker’ s

warranty depends on the laws in the country in which it was purchased.

Y our local JBL

car audio retailer can help you determine the length of

your warranty. T

o register your product, please visit www.jbl.com.

BL (T-m)

6.50

DCR (ohms)

3.58

Mms (g)

26.00

Sd(sq cm)

237.0

Cms (µm/N)

400

Vas (l)

31.6

Fs (Hz)

49.4

Qes

0.68

Qms

10.00

0.64

1wSPL (dB)

89.4

SPL 2.83V

92.9

T696
LIMITED
