6
1 Programme selector dial
The programme selector dial is divided into the
following sections:
• Cottons,
• Synthetics,
• Delicates
• Wool
/
Hand washing
• Special programmes from “Soak” to “30 Minute
wash”
• Reset/Off programme Off
The selector dial can be
turned either clockwise
or anticlockwise.
“Economy” position
corresponds to an
ENERGY SAVING
programme and “Cold”
to a cold wash.
Before setting the dial to
any position ensure that the machine is turned to the
“Off” position.
Important! At the end of the programme the
selector dial must be turned to position “Off”,
to switch the machine off.
Attention!
If you turn the programme selector dial to another
programme when the machine is working, the red
Start/Pause pilot light will flash 3 times and the
message Err is displayed on the display to indicate a
wrong selection. The machine will not perform the
new selected programme.
2 Spin button
Press this button repeatedly to change the spin speed
or to select position “None” (no spin), if you want
90°
Economy 60°
60°
30°
40°
60°
40°
30°
Economy 40°
Economy 40°
Off
Cold
Hand wash
Drain
Rinse
30 Minute wash
30°
Soak
Delicates 40°
Delicates 30°
Spin
W
ool
Cottons
Synthetics
The control panel
1 2 3 4 5 6 9
Start/Pause
Wash time
Door lock
Delay start
90°
Economy 60°
60°
30°
40°
60°
40°
30°
Economy 40°
Economy 40°
Off
Cold
Hand wash
Drain
Rinse
30 Minute wash
30°
Soak
Delicates 40°
Delicates 30°
Spin
Child lock
W
ool
8 7 10
Option Extra rinse Prewash Quick
Rinse hold
Stain
1400
900
700
500
Spin
None
Cottons
Synthetics
your laundry to be spun at a speed different from the
one proposed by the washing machine. The relevant
light will light up.
Spin speed
The following speeds are available for the different
fabrics:
• Cottons, linen:
500/700/900 max 1400 r.p.m. ;
• Synthetics and Wool/Hand wash:
500/700 max 900 r.p.m.;
• Delicates and “30 Minute wash”:
500 max 700 r.p.m.
Position “None”
By selecting the option “None” all the spinning phases
are cancelled and the last rinse water is drained.
If you select this option with programmes for cotton,
synthetics and delicates, the machine will perform
some extra rinses.
Programme options buttons
Depending on the programme, different options can be
selected together. These must be selected after
choosing the desired programme and before
depressing the “Start/Pause” button.
When these buttons are pressed, the corresponding
pilot lights illuminate. When they are pressed again, the
pilot lights go out.
If an option which is not compatible with the set
wash programme is selected, the red Start/Pause
light flashes 3 times and the message Err is
displayed for about 2 seconds.
3 Option button
Press this button repeatedly, to select only one of the
following options:
