43
ENTREE/DECODEUR
IN/DECODER
AV2
ENTREE/SORTIE
IN/OUT
ENTREE
ANT. IN
SORTIE
RF OUT
ANTENNE AV1
1
5 3 4
2
4 AV1 IN/OUT Connector enables AV connec-
tion to TV or second recorder; input recordable
when "L-1" selected.
੬
pg. 5, 24
5 RF OUT Connector enables connection to
aerial terminal of TV receiver.
੬
pg. 5
1 Mains Power Cord supplies power to recorder.
੬
pg. 5
2 ANT. IN Connector enables connection of aerial.
੬
pg. 5
3 AV2 IN Connector enables connection of
satellite receiver or second recorder; input
recordable when "L-2" selected.
੬
pg. 24, 29
* DECODER connection is not available with this
recorder.
REAR VIEW
