– 51 –
They differ according to the “DIGITAL AUDIO OUTPUT” setting. (See page 39.)
Appendix C
—Output Signals Through the OPTICAL DIGITAL
OUTPUT Terminal
Appendix D
—Channel Display
Display LFE Channel
1/0 CH C ONLY
1/0.1 CH ON C ONLY
2/0 CH L/R
2/0.1 CH ON L/R
2/0 CH L/R (L0/R0)
2/0.1 CH ON L/R (L0/R0)
2/0 CH L/R/S (Lt/Rt)
2/0.1 CH ON L/R/S (Lt/Rt)
3/0 CH L/C/R
3/0.1 CH ON L/C/R
2/1 CH L/R/S
2/1.1 CH ON L/R/S
3/1 CH L/C/R/S
3/1.1 CH ON L/C/R/S
2/2 CH L/R/LS/RS
2/2.1 CH ON L/R/LS/RS
3/2 CH L/C/R/LS/RS
3/2.1 CH ON L/C/R/LS/RS
DOLBY DIGITAL
Display Channel
1 CH Monaural
2 CH 2 ch stereo
3 CH 3 ch
4 CH 4 ch
5 CH 5 ch
6 CH 6 ch
7 CH 7 ch
8 CH 8 ch
Linear PCM and DTS
Display Channel
2/0 CH Monaural
2/0.1 CH 2 ch stereo
2/2 CH 3 ch
3/0 CH 4 ch
2/2.1 CH 5 ch
3/0.1 CH 6 ch
3/2 CH 7 ch
3/2.1 CH 8 ch
2/0 CH (down mix)
MPEG
Current outputting channel appears on the display when you press DISPLAY. (See page 17.)
Output Signals
STREAM/PCM DOLBY DIGITAL/PCM PCM ONLY
48 kHz, Linear PCM 48 kHz, Linear PCM 48 kHz, Linear PCM
48 kHz, Linear PCM 48 kHz, Linear PCM 48 kHz, Linear PCM
Dolby Digital bitstream Dolby Digital bitstream 48 kHz, Linear PCM
DTS bitstream
MPEG bitstream
48 kHz, Linear PCM 48 kHz, Linear PCM
44.1 kHz, 16 bit Linear PCM 44.1 kHz, 16 bit Linear PCM 44.1 kHz, 16 bit Linear PCM
DTS bitstream 44.1 kHz, 16 bit Linear PCM 44.1 kHz, 16 bit Linear PCM
Playback disc
DVD with 48 kHz, Linear PCM
with 96 kHz, Linear PCM
with Dolby Digital
with DTS Digital Surround
with MPEG Audio
Video CD, Audio CD
Audio CD with DTS Digital
Surround
DIGITAL AUDIO
OUT
