8
Building In
Recess dimensions
Height
(1) 1780 mm
Depth (2) 550 mm
Width (3) 560 mm
The appliance’s door has been locked in
position for transport by means of pins on
both sides.According to the door opening
direction, remove relevant pins at the top and
at the bottom.
To ensure adequate ventilation, allow the clearances
shown in figure.
50 mm
min.
200 cm 2
200 cm 2
min.
D567
It is necessary that the cabinet has a ventilation
recess with the following dimensions:
depth
50 mm
width 540 mm
The appliance is supplied with the
right door opening.
To change the opening direction of the
door proceed as in the following
instructions before installing it.
1. Unscrew the upper pin and remove the spacer
2. Remove the door.
3. Unscrew the lower pin and remove the spacer;
replace them on the opposite side.
4. Reinsert the door and screw the pin and the
spacer back in place on the opposite side.
PR01
540
50
B
T H
Before carrying out any work, remove the plug from the
power socket.
Please ensure that when the appliance is installed it is
easily accessible for the engineer in the event of a
breakdown.
13
Temperature control
The temperature within the refrigerator is
controlled by the thermostat situated in the top of
the refrigerator.
To operate the refrigerator proceed as follows:
Position 1 = minimum coldness
Position 5 = maximum coldness
Turn the thermostat control knob beyond the « ● »
position.
When you first start the refrigerator, we suggest
that you turn the thermostat control to a medium
setting.
For easier turning of this control, use a small coin.
However, if the appliance is working in unfavourable
room conditions such as
- poor ventilation,
- high temperature,
- frequent door openings,
it may be necessary to select a more suitable
setting.
Fresh food refrigeration
To obtain the best performance, do not store warm
food or evaporating liquids in the refrigerator; do
cover or wrap the food, particularly if it has a strong
flavour.
Do not cover the shelves with any protective
material, such as paper, cardboard or plastic, which
may obstruct the air circulation through them.
To help you use your refrigerator correctly, here are
some more useful hints:
Raw meat (beef, pork, lamb & wild fowl): wrap in
polythene bags and place on top of the salad
crispers.
Meat can only be stored safely in this way for
one or two days at the most.
Fruit & vegetables: these should be thoroughly
cleaned and placed in the bottom salad crispers.
Butter & cheese: these should be placed in special
airtight containers or wrapped in aluminium foil or
polythene bags to exclude as much air as possible.
Milk bottles: these should have a cap and should
be stored in the bottle rack on the door.
Using the fridge
Before use
Remove all securing tapes.Wash inside the appliance
with lukewarm water and bicarbonate of soda (5 ml
to 0.5 litre of water).
Do not use soap or detergent as the smell
may linger. Dry thoroughly.
Normal Operating Sounds
• You may hear faint gurgling or bubbling sounds
when the refrigerant is pumped through the coils
or tubing at the rear, to the cooling
plate/evaporator or to the fixed freezer shelves.
• When the compressor is on, the refrigerant is
being pumped round, and you will hear a whirring
sound or pulsating noise from the compressor.
• A thermostat controls the compressor, and you
will hear a faint ’click’ when the thermostat cuts
in and out.
