JVC CA-MXGT700 - Manual (Page 65)

– 28 –
English
CA-MXG500
Amplifier section
Output Power
SUBWOOFERS : 80 W per channel, min. RMS, driven into
6 Ω at 63 Hz with no more than 10% total
harmonic distortion.
MAIN SPEAKERS: 40 W per channel, min. RMS, driven into
4 Ω at 1 kHz with no more than 10% total
harmonic distortion.
Audio input sensitivity/Impedance
(at 1 kHz, measured at MAIN SPEAKERS)
AUX : 400 mV/50 k Ω
MIC : 5 mV/5 kΩ
Digital output: DIGITAL OUT (OPTICAL)
Signal wave length : 660 nm
Output level : –21 dBm to –15 dBm
Speakers/Impedance : Subwoofers : 6 Ω – 16 Ω
Main speakers : 4 Ω – 8 Ω
Tuner
FM tuning range : 87.50 MHz – 108.00 MHz
AM tuning range: 531 kHz – 1 602 kHz
(at 9 kHz intervals)
530 kHz – 1 710 kHz
(at 10 kHz intervals)
CD player
CD Capacity : 3 CDs
Dynamic range : 85 dB
Signal-to-noise ratio : 85 dB
Cassette deck
Frequency response
Normal (type I): 50 Hz — 14 000 Hz
Wow and flutter : 0.15% (WRMS)
Design and specifications are subject to change without notice.
General
Power requirement : AC 110 V / AC 127 V/ AC 220 V / AC
230 V — AC 240 V
, adjustable
with the voltage selector, 50 Hz / 60 Hz
Power consumption : 130 W (at operation)
17 W (on standby)
Dimensions (approx.) : 270 mm x 317 mm x 449 mm (W/H/D)
Mass (approx.) : 8.8 kg
Supplied accessories
See page 6.
