2
Parts Identification
Become familiar with the buttons and controls on the receiver before use.
Refer to the pages in parentheses for details.
Front Panel
1 POWER button and STANDBY lamp
(8)
2 FM/AM TUNING 5/∞ buttons (16)
3 FM/AM PRESET 5/∞ buttons (16, 17)
4 FM MODE button (17)
5 MEMORY button (16)
6 Display (8)
7 ADJUST button (10, 11, 21 – 23)
8 Remote sensor (7)
9 SETTING button (11 – 14)
p MASTER VOLUME control (9)
q PHONES jack (9)
w SURROUND ON/OFF button (21, 24)
e DSP MODE button (22 – 24)
r SPEAKERS ON/OFF button (9)
t INPUT ANALOG button (15)
INPUT ATT button (10)
y INPUT DIGITAL button (14)
u Source selecting buttons (8, 9, 14)
DVD, VCR, TV SOUND, CD,
TAPE/CDR, FM/AM
i SOURCE NAME button (11)
* TAPE/CDR button also functions as
the SOURCE NAME button
o CONTROL UP 5/DOWN ∞ buttons
Remote Control
1 POWER buttons (8, 27)
TV, VCR, AUDIO
2 SLEEP button (15)
3 SURROUND button (21, 24, 26)
4 SURROUND MODE button
(22 – 24, 26)
5 SOUND button (10, 21 – 23, 26)
6 TV/VIDEO button (27)
7 CD-DISC button (27)
8 Source selecting buttons (8, 9, 15)
DVD, TV SOUND, VCR, CD,
TAPE/CDR, FM/AM
9 TV VOL +/– buttons (27)
p TV CH +/– buttons (27)
q • 10 keys for selecting preset channels
(17)
• 10 keys for adjusting sound
(21 – 23, 26)
• 10 keys for operating audio/video
components (26, 27)
w ANALOG/DIGITAL button (15)
e MUTING button (9)
r VOLUME +/– buttons (9)
t Operating buttons for audio/video
components (26, 27)
1 1
REMOTE CONTROL
SURROUND
SURROUND
MODE
SOUND
TV/VIDEO CD-DISC
1
5
– SUBWOOFER + TEST
6 5 4
EFFECT – CENTER +
5
9 8
– REAR•L + – VCR CH +
5
SLEEP
– REAR•R +
MENU
5
TAPE/CDR FM/AM
MUTING
CD
TV SOUND VCR
TV VOL
TV CH
DVD
– –
+ +
VOLUME
POWER
8
1
3
4
5
6
7
8
9
w
q
r
t
2
p
7/P
RM-SRX6010J
A/V CONTROL RECEIVER
3 2
ANALOG/DIGITAL
ENTER
+10 10
+ +
–
7
£
TV VCR AUDIO
e
DVD VCR TV SOUND
AUDIO/VIDEO CONTROL RECEIVER
CONTROL DOWN UP
CD
SOURCE NAME
INPUT DIGITAL INPUT ANALOG
SPEAKERS ON/OFF DSP MODE
PHONES
SURROUND ON/OFF
FM/AM TUNING
STANDBY
POWER
FM/AM PRESET FM MODE
MEMORY
INPUT ATT
FM/AM
D I G I T A L
D I G I T A L
S U R R O U N D
1 2 3 4 5 6 7 8
q w r e t y u o
9 p
ADJUST SETTING
i
TAPE/CDR
MASTER VOLUME
