1
Heating Capacity will vary depending on the design of the home, climate, elevation,
operation and venting configuration.
2
Depth dimension includes ashlip and flue collar.
3
With maximum vent configuration
Jøtul GF 300 BV Allagash
Page 10
Venting Options & Specifications
Venting
B-Vent
Heating Capacity
1
Up to 1,300 sq.ft.
Min/Max Heat Input
15,000-26,000 (NG)
(BTU/hr)
13,500-26,000 (LP)
Efficiency
3
up to 86% Steady State
(A.F.U.E. 73%)
Safety Features
Sealed System
Optional Blower
Yes
Optional Wall Thermostat
Yes
Optional Remote control
Yes
Dimensions
Height
27 3/4”
Height w/ opt. short legs
25 1/2”
Width
22 3/4”
Depth
2
17 1/2”
Weight
185 lbs.
Venting
4” B-Vent
Clearances
Rear
2”
Side
3”
Corner
3”
11.5" deep mantel
29”
Jøtul GF 300 DV Allagash
Page 10
Venting
Direct Vent
Heating Capacity
1
Up to 1,300 sq. ft..
Min/Max Heat Input
14,000-26,000 (NG)
(BTU/hr)
14,000-26,000 (LP)
Efficiency
3
up to 88% Steady State
(A.F.U.E 72.7%)
Safety Features
Sealed System
Optional Blower
Yes
Optional Wall Thermostat
Yes
Optional Remote control
Yes
Dimensions
Height
28”
Height w/ opt. short legs
25 3/4”
Width
22 3/4”
Depth
2
17 1/2”
Weight
185 lbs.
Venting
Simpson DuraVent GS/
AmeriVent/Security/Selkirk
Clearances
Rear
2”
Side
3”
Corner
2”
10" deep mantel
29”
�������
������
��
���
������
����������
�����������
���������
�����
�������
��������
