Declaration of Conformity
We, Harman Consumer Group International
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described in this owner’s
manual are in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group International
Château du Loir, France 7/06
Harman Consumer Group, Inc.
250 Crossways Park Drive, Woodbury, NY 11797 USA
516.255.4JBL (4525) (USA only) www.jbl.com
© 2006 Harman International Industries, Incorporated.
All rights reserved.
JBL and Harman International are trademarks of
Harman International Industries, Incorporated,
registered in the United States and/or other countries.
Part No. C508/C608GTiMkIIOM7/06
A valid serial number is required for warranty coverage.
Features, specifications and appearance are subject to
change without notice.
This product is designed for mobile applications and is
not intended for connection to the mains.
C508GTi MkII C608GTi MkII Tweeter
5-1/4" (130mm) 6-1/2" (160mm)
Professional-grade Professional-grade
automotive component automotive component
speaker system speaker system
Power handling (peak) 500W 600W n/a
Power handling (RMS) 125W 150W n/a
Frequency response 58Hz – 21kHz 50Hz – 21kHz n/a
Nominal impedance 4 ohms 4 ohms n/a
Sensitivity (2.83V/1m) 88dB 89dB n/a
Crossover 4th-Order Linquitz-Riley Acoustic, 3500Hz, 24dB/octave n/a
Cutout diameter 4-5/8" (118mm) 5-1/8" (131mm) 1-3/4" (45mm)
Mounting depth 2-3/8" (61mm) 2-11/16" (69mm) 1" (25.4mm)
Thiele and Small Parameters
Revc 3.00 3.50 3.14
Levc 0.16 0.25 0.01
Sd 0.0086 0.0117 0.0006
BL 6.00 6.69 2.22
Vas 3.34 7.90 0.0016
Cms 322.0 405.0 31
Mms 12.07 18.21 0.46
Mmd 11.61 17.48 0.452
Fs 80.7 58.61 1320
Qms 6.51 9.01 1.8
Qes 0.51 0.52 2.463
Qts 0.47 0.50 1.04
Top-plate thickness 3/16" (5.08mm) 1/4" (6.35mm) n/a
Voice-coil length 1/2" (12.7mm) 11/16" (16.51mm) n/a
Voice-coil diameter 2" (50.8mm) 2" (50.8mm) 1" (25.4mm)
Xmax 1/8" (3.44mm) 1/8" (3.44mm) n/a
SPECIFICATIONS
